TRNSYS18 新機能概要(10)新しいコンポーネント

TRNSYS18では新しいコンポーネントが多数追加されています。設計の初期段階で使えるシンプルなコンポーネントが用意されています。

6.    新しいコンポーネント

標準ライブラリには、初心者がソフトウェアの使い方を簡単に理解できるようにする多数の基本コンポーネントモデルが追加されています。
また、これらの基本コンポーネントは、設計の初期段階で詳細情報が未定の段階でTRNSYSの使用を容易にします。
これらの基本コンポーネントは、設計が進んで詳細が決まった段階で、より詳細なコンポーネントに置き換えることができます。
例えば、設計プロセスの早い段階では、全体の冷房負荷は想定できているが使用する冷却コイルはまだ選択されていない場合があります。はじめは容量だけを指定する基本的な冷却コイルモデルのコンポーネントを使用し、冷却コイルが設計された後、詳細な冷却コイルモデルのコンポーネントへ置き換えることができます。

6.1.    New Controller Components

Simple Thermostat
Simple Humidistat
Dehumidistat
Aquastat (heating and cooling)
Tempering Valve (heating and cooling)
Delayed Inputs
Simple Differential Controller

6.2.    New Electrical Components

Four Parameter PV
Five Parameter PV

6.3.    New HVAC Components

Electric Resistance Heater (air and liquid)
Gas Heater (air and liquid)
Air Cooled Chiller
Air-to-Air Heat Pump
Boiler
Chilled Water Coil (dry or wet and partially wet)
Simple Cooling Tower
Direct Expansion Coil
Fan Coil
Furnace
Hot Water Coil (constant UA and varying UA)
Water Cooled Chiller
Water-to-Air Heat Pump
Residential Split System AC
PTAC
VAV Air Handler
VAV Air Handler with PFP Boxes Detailed Cooling Tower

6.4.    New Hydronics Components

Duct
Constant Speed Fan
Variable Speed Fan
Air Diverter
Return Plenum

6.5.    New Loads and Structures Components

NIST Simple Infiltration
Simple Natural Ventilation

6.6.    New Thermal Storage Components

Simple Gas Heated Liquid Storage
Simple Electric Heated Liquid Storage
Constant Volume Liquid Storage – with HX Constant Volume Liquid Storage – no HX

6.7.    New Utility Components

Calling External Programs (MATHIS)
Calling External Programs (Python)
Calling External Programs (CoolProp) – 他のTypeから呼び出すことができるサブルーチンを提供します。
